Geberit Alpha Concealed Cistern 3 and 5.8 Litres with Dual Flush Plate - Installation Height 109cm

The Geberit Alpha Concealed Cistern is an innovative bathroom solution designed for modern living. It is suitable for use with both floor-standing and wall-hung WCs and is compact enough for installation in smaller spaces.

Fitted with a dual flush plate, this concealed cistern offers a seamless and uncluttered appearance. The dual flush system minimises water consumption by providing short and long flush options. Its smooth white finish adds elegant simplicity to any bathroom setting.

Key Features

✔ Suitable for dual flush with front actuation
✔ Water supply connection on rear or top centre
✔ Complies with EN 14055, Class II standards
✔ Concealed cistern with dual flush plate
✔ Choice of flush plate: Square or Round buttons
✔ White finish

Technical Specifications

• Size (mm): 440 x 120 x 780 [Width x Depth x Height]
• Size (cm): 44 x 12 x 78 [Width x Depth x Height]
• Material: Plastic
• Flow Pressure: 0.1–10 Bar
• Maximum Water Temperature: 25°C
• Flush Volume (Factory Setting): 5.8L / 3L
• Small Flush Adjustment Range: 3–4L
• Installation Height: 109cm

Installation & Compatibility

• Flush bend fitted
• Adjustable depth
• Suitable for masonry walls
• Fully insulated against condensation
• Immediate post-flush possible (factory setting)
• Suitable for floor-standing and wall-hung WCs
• For installation in:

• • Part-height prewall

  • Room-height prewall

  • Room-height installation walls

Protection & Maintenance

• Protection box for service opening
• Protects against moisture and dirt
• Can be cut to length

Scope of Delivery

• Protection Plug
• 2 × Fixing Brackets
• Fastening Material
• Flush Bend Extension: Ø45mm
• Alpha01 Flush Plate (Square or Round Button)
• Protection Box for Service Opening
• Geberit Pull Disc for Type 212 Flush Valve (Omega 82cm)
• Water Supply Connection R 1/2"
• Integrated Angle Stop Valve and Hand Wheel
• Compatible with MasterFix and MeplaFix
